Solid-Ink Coding Machine

Coding Machine

Description:.
Adopt photoelectric mechanism technology, featuring automatic temperature control, auto counting & adjustable print position.

Adopt solid-ink coding with selectable color, featuring legible printing, instant printing-instant drying and strong adhesion.

With dual-use print wheel, suitable for R type and T type arrangement. T type arrangement: 1~11 lines, 1~10 characters/Line; R type arrangement: 1~8 lines, 1~8 characters/Line. There’re types in size of 1.5mm, 2mm, 2.5mm & 3mm for selection.

Fit for printing codes on paper, thin paper board, plastic film and aluminum foil.

The machine is automatic, with high speed & high efficiency up to 300pcs/minute.

The machine’s coding type can be customized to be color ribbon printing, better for printing codes on the package that needed to be steamed & boiled.

Parameters:

	MY-380F	MY-380F/W
Voltage(V/Hz)	AC 220/50 110/60
Power(W)	180
Solid Ink Roller(mm)	35×32 35×16
Printing Speed(pcs(/min)	≤300
Object Size(mm)	L:50-500 W:30-190	L:50-550 W:30-300
Max. Printing Line	T Arrange(10.5PT):11Lines (Max.10 characters/line) R Arrange(10.5PT):8Lines(Max.8 characters/line)
Printing Size(mm)	Within 60-250
Type Size(mm)	2×1.5( 8PT ) 2.5×2(9PT) 3×3(10.5PT) 4×2.5(18PT)
External Dimensions (L×W×H)(mm)	440×345×300	440×465×300
Net Weight(Kg)	23	26
